21 ASUS Pocket Wireless Access Point
2. Installation
2.3 Mounting
Aside from desktop placement, you may install the ASUS Pocket Wireless AP
vertically on a concrete or wooden wall using the mounting hooks at the
bottom of the and a mounting screw.
To mount the ASUS Pocket Wireless AP on a concrete or wooden wall:
1. Locate the mounting hook at the bottom of the device.
2. Select an ideal location for the device following the considerations mentioned
in section 2.2.1.
3. Tighten a round head screw on the concrete or wooden wall until only 1/4” is
showing.
4. Latch the device into the screw.
Adjust the screw if you cannot latch the device or if the screw is too loose.
