Tyco Electronics Power Systems 21
Data Sheet
August 22, 2006
36 Vdc to 75 Vdc Input; 1.2 Vdc to 5.0 Vdc Output; 10 A to 20 A
QW010/015/020 Series Power Modules: dc-dc Converters;
Outline Diagram for Through-Hole Module
Dimensions are in millimeters and (inches).
Tolerances: x.x mm ± 0.5 mm (x.xx in. ± 0.02 in.) [unless otherwise indicated]
x.xx mm ± 0.25 mm (x.xxx in. ± 0.010 in.)
8.5
(.335)
Max
SIDE VIEW
TOP VIEW
BOTTOM VIEW
4.5
(0.18)
MIN
ø
1.00
(.040)
6 Places
ø
1.50
(.060)
2 Places
V IN (+)
ON/OFF
V IN (-)
V OUT (+)
+SENSE
TRIM
-SENSE
V
OUT (-)
57.9
(2.28)
36.8
(1.45)
LABEL LOCATION AND
ORIENTATION (CONTENTS
WILL VARY)
3.6
(0.14)
50.8
(2.00)
7.62
(.300)
3.81
(.150)
11.43
(.450)
15.24
(.600)
10.8
(0.43)
15.24
(0.600)
7.62
(0.300)
