GE Data Sheet
SHHD001A3B Hammerhead Series; DC-DC Converter Power Modules
18-75Vdc Input; 12Vdc, 1.3A, 15W Output
October 30, 2013 ©2012 General Electric Company. All rights reserved. Page 3
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Output Voltage Set-point
12.0 V
O
V
O, set
11.82 12.00 12.18 V
dc
(V
IN
=24 to 48V
dc
, I
O
=I
O, max
, T
A
=25°C)
Output Voltage
All V
O
-3.0  +3.0 % V
O, set (Over all operating input voltage, resistive load, and temperature
conditions until end of life)
Adjustment Range
All V
O, adj
-10 +10 % V
O, set
Selected by external resistor
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
) All  0.05 0.2 % V
O, set
Load (I
O
=I
O, min
to I
O, max
) All  0.05 0.2 % V
O, set
Temperature (T
ref
=T
A, min
to T
A, max
) All   1.0 % V
O, set
Output Ripple and Noise on nominal output
Measured with 10uF Tantalum||1uF ceramic
(V
IN
=24 to 48V
dc
, I
O
=80%I
O, max
, T
A
=25°C)
RMS (5Hz to 20MHz bandwidth)
All
  50 mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth)   150 mV
pk-pk
External Capacitance All C
O, max
0  470 μF
Output Current All I
o
0  1.3 A
dc
Output Current Limit Inception (Hiccup Mode) All I
O, lim
1.4 1.8  A
dc
Output Short-Circuit Current
All I
O, s/c
  0.8 A
rms
V
O
≤ 250 mV @ 25°C
Efficiency
V
IN
=24-48V
dc
, T
A
=25°C, I
O
=I
O, max
All η 86.0 87.5  %
Switching Frequency (Fixed)
All f
sw
 350  kHz
V
IN
=24 to 48V
dc
and I
O
= I
O, max
Dynamic Load Response
(  I
O
/  t=0.1A/  s, V
IN
=24 to 48V
dc
, T
A
=25°C)
Load Change from I
O
= 50% to 75% or 25% to 50% of I
O,max
:
Peak Deviation All V
pk
 3.0  % V
O, set
Settling Time (Vo<10% peak deviation) All t
s
 800   s
Isolation Specifications
Parameter Symbol Min Typ Max Unit
Isolation Capacitance C
iso
 1000  pF
Isolation Resistance R
iso
10   MΩ
I/O Isolation Voltage All   2250 Vdc
General Specifications
Parameter Min Typ Max Unit
Calculated Reliability based upon Telcordia SR-332 Issue 2: Method I Case 3
(V
IN
=48V
dc
, I
O
=80%xI
O, max
, T
A
=40°C, airflow = 200 LFM, 90% confidence)
FIT 127.1 10 9 /Hours
MTBF 7,866,035 Hours
Weight  8.0 (0.28)  g (oz.)
