GE Industrial Solutions SHHD001A3B Hammerhead Series - Manual (Page 15)

GE Data Sheet
SHHD001A3B Hammerhead Series; DC-DC Converter Power Modules
18-75Vdc Input; 12Vdc, 1.3A, 15W Output
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
October 30, 2013 ©2012 General Electric Company. All rights reserved. Version 1.44
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Device Codes
Device Code
Input
Voltage Range
Output
Current
Output
Voltage
Remote
On/Off Logic
Connector
Type
Comcode
SHHD001A3B4Z 24V/48V (18-75Vdc) 1.3A 12.0V Positive Through hole 150024947
SHHD001A3B41Z 24V/48V (18-75Vdc) 1.3A 12.0V Negative Through hole CC109172937
SHHD001A3B41-SRZ 24V/48V (18-75Vdc) 1.3A 12.0V Negative Surface mount 150023383
Device Options
