GE
Preliminary Data Sheet
3A Analog PicoDLynx
TM
: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.6Vdc to 5.5Vdc output; 3A Output Current
December 7, 2012
©2012 General Electric Company. All rights reserved.
Page 3
Electrical Specifications
(continued)
Parameter
Device
Symbol
Min
Typ
Max
Unit
Output Voltage Set-point (with 0.1% tolerance for external
resistor used to set output voltage)
All
V
O, set
-1.0 +1.0
%
V
O, set
Output Voltage (Over all operating input voltage, resistive
load, and temperature conditions until end of life)
All
V
O, set
-3.0
⎯
+3.0 %
V
O, set
Adjustment Range (selected by an external resistor)
(Some output voltages may not be possible depending on
the input voltage – see Feature Descriptions Section)
All V
O
0.6 5.5 Vdc
Remote Sense Range
All
0.5
Vdc
Output Regulation (for V
O
≥ 2.5Vdc)
Line (V
IN
=V
IN, min
to V
IN, max
) All
⎯
+0.4 %
V
O, set
Load (I
O
=I
O, min
to I
O, max
) All
⎯
10 mV
Output Regulation (for V
O
< 2.5Vdc)
Line (V
IN
=V
IN, min
to V
IN, max
) All
⎯
5 mV
Load (I
O
=I
O, min
to I
O, max
) All
⎯
10 mV
Temperature (T
ref
=T
A, min
to T
A, max
) All
⎯
0.4 %
V
O, set
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
and I
O
=I
O, min
to I
O, max
Co = 0.1μF // 22 μF
ceramic capacitors)
Peak-to-Peak (5Hz to 20MHz bandwidth)
All
⎯
50 100 mV
pk-pk
RMS (5Hz to 20MHz bandwidth)
All
20
38
mV
rms
External Capacitance
1
Without the Tunable Loop
TM
ESR ≥ 1 mΩ
All
C
O, max
10
⎯
22
μF
With the Tunable Loop
TM
ESR ≥0.15 mΩ All
C
O, max
10
⎯
TBD
μF
ESR ≥ 10 mΩ All
C
O, max
10
⎯
TBD
μF
Output Current (in either sink or source mode)
All
I
o
0 3 Adc
Output Current Limit Inception (Hiccup Mode)
(current limit does not operate in sink mode)
All I
O, lim
200 %
I
o,max
Output Short-Circuit Current
All
I
O, s/c
0.5
Arms
(V
O
≤250mV) ( Hiccup Mode )
Efficiency
V
O,set
= 0.6Vdc
(8Vin)
η
75
%
V
IN
= 12Vdc, T
A
=25°C V
O, set
= 1.2Vdc
η
82.8
%
I
O
=I
O, max ,
V
O
= V
O,set
V
O,set
= 1.8Vdc
η
88.2
%
V
O,set
= 2.5Vdc
η
89.9
%
V
O,set
= 3.3Vdc
η
91.6
%
V
O,set
= 5.0Vdc
η
93.9
%
Switching Frequency
All
f
sw
⎯
600
⎯
kHz
1
External capacitors may require using the new Tunable Loop
TM
feature to ensure that the module is stable as well as getting the best
transient response. See the Tunable Loop
TM
section for details.
