GE
Preliminary Data Sheet
3A Analog PicoDLynx
TM
: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.6Vdc to 5.5Vdc output; 3A Output Current
December 7, 2012
©2012 General Electric Company. All rights reserved.
Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings
only, functional operation of the device is not implied at these or any other conditions in excess of those given in the operations
sections of the data sheet. Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter
Device
Symbol
Min
Max
Unit
Input Voltage
All
V
IN
-0.3 15 Vdc
Continuous
Operating Ambient Temperature
All
T
A
-40 85 °C
(see Thermal Considerations section)
Storage Temperature
All
T
stg
-55 125 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.
Parameter
Device
Symbol
Min
Typ
Max
Unit
Operating Input Voltage
All
V
IN
3 ⎯
14.4 Vdc
Maximum Input Current
All
I
IN,max
2.4
Adc
(V
IN
=3V to 14V, I
O
=I
O, max
)
Input No Load Current
(V
IN
= 12.0Vdc, I
O
= 0, module enabled)
V
O,set
= 0.6 Vdc
I
IN,No load
TBD
mA
V
O,set
= 5Vdc
I
IN,No load
38
mA
Input Stand-by Current
(V
IN
= 12.0Vdc, module disabled)
All I
IN,stand-by
0.65
mA
Inrush Transient
All
I
2
t
1
A
2
s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN
=0 to
14V
,
I
O
= I
Omax
; See Test Configurations)
All
15
mAp-p
Input Ripple Rejection (120Hz)
All
-60
dB
