3A Digital PicoDLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 3A Output Current
April 29, 2013 ©2013 General Electric Company. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings
only, functional operation of the device is not implied at these or any other conditions in excess of those given in the operations
sections of the data sheet. Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage All V
IN
-0.3 15 V
Continuous
SEQ, SYNC, VS+ All 7 V
CLK, DATA, SMBALERT All 3.6 V
Operating Ambient Temperature All T
A
-40 85 °C
(see Thermal Considerations section)
Storage Temperature All T
stg
-55 125 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
3 ⎯ 14.4 Vdc
Maximum Input Current All I
IN,max
2.8 Adc
(V
IN
=3V to 14V, I
O
=I
O, max
)
Input No Load Current
(V
IN
= 12Vdc, I
O
= 0, module enabled)
V
O,set
= 0.6
Vdc
I
IN,No load
17.5 mA
V
O,set
=
5Vdc
I
IN,No load
43 mA
Input Stand-by Current
(V
IN
= 12Vdc, module disabled)
All I
IN,stand-by
6.4 mA
Inrush Transient All I 2 t 1 A 2 s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN
=0 to 14V
,
I
O
= I
Omax
; See
Test Configurations)
All 100 mAp-p
Input Ripple Rejection (120Hz) All -57 dB
