Data Sheet
July 11, 2011 Naos Raptor 20A: Non Isolated Power Module:
4.5 – 14Vdc input; 0.59Vdc to 6Vdc Output; 20A output current
LINEAGE POWER 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only, functional operation of the device is not implied at these or any other conditions in
excess of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage
Continuous All V
IN
-0.3 15 Vdc
Operating Ambient Temperature All T
A
-40 85 °C
(see Thermal Considerations section)
Storage Temperature All T
stg
-55 125 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
4.5 12.0 13.8 Vdc
Maximum Input Current All I
IN,max
20 Adc
(V
IN
= V
IN, min
to V
IN, max
, I
O
=I
O, max
V
O,set
= 3.3Vdc)
Input No Load Current V
O,set
= 0.6 Vdc I
IN,No load
50 mA
(V
IN
= 12Vdc, I
O
= 0, module ON) V
O,set
= 5.0Vdc I
IN,No load
110 mA
Input Stand-by Current All I
IN,stand-by
6.08 mA
(V
IN
= 12Vdc, module disabled)
Inrush Transient All I 2 t 1 A 2 s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN, min
to
V
IN, max,
I
O
= I
Omax
; See Test configuration section)
All 34.4 mAp-p
Input Ripple Rejection (120Hz) All 43 dB
