Installation Guide SG Series UL Battery cabinets
UPS Cabinet KVA
Fuse/Circuit Breaker (CB)
Fuse Size CB Size
Circuit Breaker
Torque Value
SG
44"
10 1 Fuse mod in each cab + 1 CB mod in Master
35 30
See Circuit Breaker
SG
44"
20 1 Fuse mod in each cab + 1 CB mod in Master
60 60
See Circuit Breaker
SG
44"
30 1 Fuse mod in each cab + 1 CB mod in Master
80 80
See Circuit Breaker
SG
44"
40 1 Fuse mod in each cab + 1 CB mod in Master
100 100
See Circuit Breaker
SG
44"
50 1 Fuse mod in each cab + 1 CB mod in Master
125 125
See Circuit Breaker
SG
44"
80 1 Fuse mod in each cab + 1 CB mod in Master
200 200
See Circuit Breaker
SG
44"
100 1 Fuse mod in each cab + 1 CB mod in Master
250 250
See Circuit Breaker
SG
44"
120 1 Fuse mod in each cab + 1 CB mod in Master
300 300
See Circuit Breaker
SG
44"
150 1 Fuse mod in each cab + 1 CB mod in Master
400 400
See Circuit Breaker
SG
44"
225 1 Fuse mod in each cab + 1 CB mod in Master
300 600
See Circuit Breaker
SG
44"
300 1 Fuse mod in each cab + 1 CB mod in Master
400 800
See Circuit Breaker
SG
44"
400
1 CB mod in each cab
500
See Circuit Breaker
SG
44"
500
1 CB mod in each cab
600/400 See Circuit Breaker
SG
44"
750
1 CB mod in each cab /Fuses in Transition
2000
600
275 in-lbs
5.6 WARRANTY
For warranty on batteries and other components of the UPS Battery Cabinets refer to GE UPS Limited Warranty
Rider document.
