—————— I/O Expansion card —————— 8
SIEI
3.3 FUNCTIONAL OVERVIEW
31
32
33
34
DIGIT
AL
INPUTS
CONNECTOR
XDIO
112
114
101
100
111
212
214
211
312
314
311
412
414
411
RELA
Y
OUTPUTS
CONNECTOR
XCQ00
N.Closed
N.Open
COM
N.Closed
N.Open
COM
N.Closed
N.Open
COM
N.Closed
N.Open
COM
RELA
Y
OUTPUTS
CONNECTOR
XCQ01
35
DIO
DI1
DI2
DI3
GND
36
37
38
39
DIGIT
AL
INPUTS
CONNECTOR
XDIO
40
DI4
DI5
DI6
DI7
GND
+24V
0V (COM)
POWER SUPPLY
CONNECTOR XSC
I/O available depending on drive firmware version
Drive firmware 1.X from 2.X
Digital Inputs 4 8
Relay Outputs 4 4
exp50
