7 —————— I/O Expansion card ——————
D8R4
3. TERMINAL BOARD POINTS
3.1 DIGITAL INPUTS TERMINAL BOARD POINTS
Connectors XDI0 and XDI1 have different ground connection.
Connector
Terminal 31 32 33 34 35 36 37 38 39 40
Function DI0 DI1 DI2 DI3 GND DI4 DI5 DI6 DI7 GND
exp10
DIGITAL INPUTS
XDI1 XDI0
3.2 RELAY OUTPUTS TERMINAL BOARD POINTS
Relay outputs need a +24V (60mA) supply voltage.
The Drive TB can be used to supply 24VDC power. AV-300i 24VDC supply
maximum output = 120 mA total including Encoder, LAN, Expansion card and
DGF (or 350 mA without DGF).
Connector
Relay
Terminal 114 111 112 214 211 212
Function N.Open COM N.Closed N.Open COM N.Closed
Connector
Relay
Terminal 314 311 312 414 411 412
Function N.Open COM N.Closed N.Open COM N.Closed
exp20
R2 R3
RELAY OUTPUTS
RELAY OUTPUTS
XCQ1
XCQ0
R0 R1
Connector
Terminal 100 101
Function 0V power supply +24V power supply
exp30
RELAY OUTPUTS POWER SUPPLY
XSC
