Data sheet, Electrical specifications, Continued) – GE Industrial Solutions JRCK017A0S32R0 Orca Series User Manual
Page 3
GE
Data Sheet
JRCK017A0S32R0 Orca Series; DC-DC Converter Power Modules
36–62 Vdc Input; 32.0Vdc Output; 17.0Adc Output
October 11, 2013
©2012 General Electric Company. All rights reserved.
Page 3
Electrical Specifications
(continued)
Parameter
Device
Symbol
Min
Typ
Max
Unit
Output Voltage Set-point
(V
IN
=V
IN,nom
, I
O
=I
O, max
, T
c
=25°C)
All V
O, set
31.5 32 32.5 V
dc
Output Voltage Set-Point Total Tolerance
(Over all operating input voltage, resistive load, and
temperature conditions until end of life)
All V
O
31.0
33.0
V
dc
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
) All
0.1 0.2 %V
o,set
Load (I
O
=I
O, min
to I
O, max
) All
0.1 0.2 %V
o,set
Temperature (T
c
= -40ºC to +100ºC)
All
0.02 %/°C
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
and I
O
=I
O, min
to I
O, max
)
RMS (5Hz to 20MHz bandwidth)
All
45 55 mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth)
All
80
200
mV
pk-pk
External Capacitance
(ESR
> 2.5 mΩ)
1
All, except -T
C
O
440 6500
μF
Without the Tunable Loop
(ESR
MAX
= 80mΩ)
1
-T
C
O,
440 470 μF
With the Tunable Loop
(ESR > 50 mΩ)
2
-T C
O
440
10,000
μF
Output Power (V
o
=32V to 35.2V)
All
P
O,max
544 W
Output Current
All
I
o
0
17.0
A
dc
Output Current Limit Inception (Constant current until
V
o
<
V
trimMIN
, duration <4s)
All
I
O, lim
18.5
22.0 A
dc
Output Short Circuit Current (V
O
≤ 0.25V
dc
) All
I
O, sc
2 A
rms
Efficiency
V
IN
=V
IN, nom
, T
c
=25°C I
O
=I
O, max ,
V
O
= V
O,set
All
η 95.0
95.1
%
Switching Frequency
f
sw
175
kHz
Dynamic Load Response
(Io/t=1.0A/10s; V
IN
=V
IN
,
nom
; T
c
=25°C;
Tested with a 470 μF aluminum and a 10 µF ceramic
capacitor across the load.)
Load Change from I
O
= 25%-50%-25% of I
O,max
:
Peak Deviation
Settling Time (V
O
<10% peak deviation)
All
V
pk
t
s
2
1.5
%V
O, set
ms
Load Change from I
O
= 50%-75%-50% of I
O,max
:
Peak Deviation
Settling Time (V
O
<10% peak deviation)
All
V
pk
t
s
2
1.5
%V
O, set
ms
(Io/t=2.0A/s; V
IN
=V
IN,nom
; T
C
=25°C;
Tested with a 3x330 μF aluminum and a 10 µF ceramic
capacitor across the load.
AC Load (100Hz, 50% duty cycle) Change from I
O
= 0%-75%-0%
of I
O,max
:
Peak Deviation
All
V
pk
t
s
4
1.5
%V
O, set
ms
Load Change from I
O
= 75% to 50% of I
O,max
:
Peak Deviation
Settling Time (V
O
<10% peak deviation)
All
V
pk
t
s
4
1.5
%V
O, set
ms
(Io/t=10%I
O,max
/10s; V
IN
=V
IN
,
nom
; T
c
=25°C; Tested with a 3000
μF aluminum and a 10 µF ceramic capacitor across the load,
see Figure 16.
Load Change from I
O
= 0%-120% of I
O,max
:
Peak Deviation
Settling Time (V
O
<10% peak deviation)
All
V
pk
t
s
2
1.5
%V
O, set
ms
Load Change from Io= 120% to 50% of Io,max:
Peak Deviation
Settling Time (Vo<10% peak deviation)
All
V
pk
t
s
2
1.5
%V
O, set
ms
1
Note: use a minimum 2 x 220uF output capacitor. Recommended capacitor is Nichicon CD series, 220uF/35V. If the ambient temperature is less
than -20
O
C, use more than 3 of recommended minimum capacitors.
2
External capacitors may require using the new Tunable Loop feature to ensure that the m
odule is stable as well as getting the best transient
response. See the Tunable Loop section for details.
