Data Sheet
September 3, 2013

Austin Superlynx

SMT Non-isolated Power Modules:

3.0 – 5.5Vdc input; 0.75Vdc to 3.63Vdc Output; 16A output current

LINEAGE

POWER

Document No: DS03-081 ver. 1.45

PDF name: superlynx_smt_3v-5.5v.pdf

Ordering Information

Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 3. Device Codes

Product codes

Input

Voltage

Output

Voltage

Output

Current

Efficiency

3.3V @ 16A

Connector

Type

Comcodes

AXH016A0X3-SR

3.0 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0% SMT 108979519

AXH016A0X3-SRZ

3.0 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0% SMT 108995180

AXH016A0X3-SR12*

3.0 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0% SMT 108993416

AXH016A0X3-SR12Z* 3.0 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0% SMT

CC109104477

* -12 code has 100Ω resistor between sense and output pins, internal to the module.

Standard code, without –12 suffix, has 10Ω resistor between sense and output pins.
-Z refers to RoHS-compliant parts
