CAR1212FP series rectifier
Input: 85Vac to 264Vac; Output: 12 Vdc @ 1250W; 5 Vdc @ 0.5A
July 20, 2012 ©2012 General Electric Company. All rights reserved. Page 3
12V
dc
MAIN OUTPUT (continued)
Parameter Device Symbol Min Typ Max Unit
Remote ON/OFF delay time
All
20 ms
Turn-ON rise time (10 – 90% of V
out
) 50 ms
Transient response 50% step [10%-60%, 50% - 100%]
(di/dt – 1A/µs, recovery 300µs)
V
out
-5 +5 %V
out
Programmable range (hardware & software) 11.4 12.6 V
dc
Overvoltage protection, latched
(recovery by cycling OFF/ON via hardware or software)
14.5 15 15.5 V
dc
Output current V
in
= HL
V
in
= LL
I
out
0
104
83.5
A
dc
Current limit, Hiccup (programmable level) HL / LL 110 135 % of FL
Active current share -5 +5 % of FL
AUXILIARY OUTPUT
Parameter Device Symbol Min Typ Max Unit
Set point All V
out
5.0 V
dc
Overall regulation (load, temperature, aging) All V
out
-5 +5 %
Ripple and noise All 50 mVp-p
Output current All I
out
0 0.5 A
dc
Isolation Output/Frame All 50 V
dc
Environmental, Reliability
Parameter Min Typ Max Units Notes
Ambient Temperature
Operating
Altitude Operating
Power Derating
-10 50
1524/5k
2.5
2.0
°C
m / ft
%/°C
C/1000 ft
Air inlet from sea level to 5,000 feet.
51°C to 70C
Above 5,000 ft
Storage
Altitude non-operating -40 85
8200/30k
°C
m / ft
Acoustic noise 45 dbA Full load, 25C
Over Temperature Protection 110/95 °C Shutdown / restart
Humidity Operating
Storage
30
10 95
95
%
Relative humidity, non-condensing
Shock and Vibration acceleration 6 Grms NEBS GR-63-CORE, Level 3, 20 -2000Hz, min 30 minutes
Earthquake Rating 4 Zone
NEBS GR-63-CORE, all floors, Seismic Zone 4 Designed
and tested to meet NEBS specifications.
MTBF
320,000
100,000
hrs
Full load, 25C per Bellcore RPP
Full load, 50C per Bellcore RPP
