GE Energy Preliminary Data Sheet
ACE184 Series Power Shelf
Main Output: 600A; Standby output: 8A
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
October 29, 2012 ©2012 General Electric Company. All rights reserved. Page 6
Connector Pin Assignments
Signal Connector: shelf end: Tyco AMP P/N 1-5499786-1
Mate: Tyco AMP P/N 1-1658621-1
P
in Signal Function Pin Signal Function Pin Signal Function
1 INPUT OK 1 INPUT OK 1 21 On / Off 3 Remote On / Off 3 41 N.C.
2 DC OK 1 DC OK 1 22 Imon 3 Current readout 3 42 I_share Current sharing
3 Mod present 1 Module present 1 23 N.C. 43 V_prog Voltage Setting
4 Temp OK 1 Temp OK 1 24 Fault 3 Fault 3 44 INT I²C interrupt
5 On / Off 1 Remote On / Off 1 25 INPUT OK 4 INPUT OK 4 45 SCL I²C clock line
6 Imon 1 Current readout 1 26 DC OK 4 DC OK 4 46 SDA I²C data line
7 N.C. 27 Mod present 4 Module present 4 47 WP Write Protect
8 Fault 1 Fault 1 28 Temp OK 4 Temp OK 4 48 RS + Positive sense
9 INPUT OK 2 INPUT OK 2 29 On / Off 4 Remote On / Off 4 49 RS - Negative sense
10 DC OK 2 DC OK 2 30 Imon 4 Current readout 4 50 RTN Signal return
11 Mod present 2 Module present 2 31 N.C. 51 Shelf Address A2 pin
12 Temp OK 2 Temp OK 2 32 Fault 4 Fault 4 52 Vsb standby output
13 On / Off 2 Remote On / Off 2 33 N.C. 53 Vsb standby output
14 Imon 2 Current readout 2 34 N.C. 54 Vsb standby output
15 N.C. 35 N.C. 55 Vsb standby output
16 Fault 2 Fault 2 36 N.C. 56 N.C.
17 INPUTOK 3 INPUT OK 3 37 N.C. 57 Vsb_rtn standby return
18 DC OK 3 DC OK 3 38 N.C. 58 Vsb_rtn standby return
19 Mod present 3 Module present 3 39 N.C. 59 Vsb_rtn standby return
20 Temp OK 3 Temp OK 3 40 N.C. 60 Vsb_rtn standby return
Ordering Information
Please contact your GE Energy Sales Representative for pricing, availability and optional features.
PRODUCT DESCRIPTION PART NUMBER
600A Shelf Power Shelf capable of delivering 600A of main output and 8A of Standby power ACE184RUW12XZ01A
