GE Energy Preliminary Data Sheet
ACE184 Series Power Shelf
Main Output: 600A; Standby output: 8A
October 29, 2012 ©2012 General Electric Company. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings
only, functional operation of the device is not implied at these or any other conditions in excess of those given in the operations
sections of the data sheet. Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Operating Ambient Temperature All TA -10 70 °C
Storage Temperature All Tstg -40 85 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.
Parameter Device Symbol Min Typ Max Unit
OUTPUT
Main output
All I
out
0 600 A
dc
Standby Output All I
out
0 8 A
dc
Isolation 1 Output - Ground All 500 V
dc
Port Phenomena test criteria Reference standard
Enclosure ESD (immunity) 8 kVair 4 kVcontact A EN 61000-4-2
1
Isolation in the context of this data sheet documents the capability of the shelf. Actual isolation capability may be further reduced by the isolation
capability of the utilized modules. Consult the module data sheet for actual capability.
