DEH41025 Installation Instructions
g
Record Plus ™
Molded Case Circuit Breaker
Accessories
DEH41025
Rotary Handle Operator, Type
FENRH
Congratulations and thank you for choosing the
Record Plus ™ family of current-limiting circuit
breakers. The UL-listed Type FENRH rotary handle
operator kit is suitable for use with the FE250 circuit
breaker series.
Record Plus ™ circuit breakers are designed with a
full line of integrated accessories. All units use the
latest in integrated modular circuit breaker
technology for flexibility in application and
maximizing the product’s utilization and
capabilities.
All Record Plus ™ circuit breakers are listed by
Underwriters Laboratories to the UL489 standard.
Record Plus ™ circuit breakers and their accessories
are designed and manufactured to exceed our global
customers’ high standards for reliability and quality.
WARNING: DANGER of electrical shock or injury.
Ensure that ALL electrical power supplies are OFF before
installing or removing any devices. The breaker, trip unit,
or accessories MUST ONLY be installed and serviced by
QUALIFIED personnel. See NEMA publication AB4.
AVERTISSEMENT: Danger contre les risques
d'électrocutions. S'assurer avant TOUTES
manipulations du disjoncteur que les différentes
sources d'alimentation sont en position OFF. Les
disjoncteurs, unités de protection, ou accessoires
doivent être installés par des personnes qualifiées et
habilitées. Lira NEMA publication AB4.
CAUTION: This product is NOT suitable for use
in equipment not specifically design to accept it.
Contact the equipment manufacturer for possible
equipment modifications.
ATTENTION: Cet appareil nedoit pas etre
employe dans un equipement non specialement
adapte a cet effet. Contactez le constructeur
concernant les possibles modifications a apporter
a l'equipement.
Figure 1. FENRH Rotary Handle Kits mounted on
Record Plus ™ FE250 circuit breaker.
Figure 1a. FENRN
(Shallow Door Mount).
Figure 1b. FENRT
(Extended Shaft Door Mount).
