GE
Data Sheet
12V Austin MicroLynx
TM
5A: Non-Isolated DC-DC Power Modules
10Vdc –14Vdc input; 0.75Vdc to 5.5Vdc output; 5A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243
, or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
May 6, 2013
©2013 General Electric Company. All rights reserved.
Version 1.53
Ordering Information
Please contact your GE representative for pricing, availability and optional features.
Table 3. Device Codes
Device Code
Input
Voltage
Range
Output
Voltage
Output
Current
Efficiency
3.3V@ 6A
On/Off
Logic
Connector
Type
Comcodes
AXA005A0X-SR
10 – 14Vdc
0.75 – 5.5Vdc
5 A
89.0%
Negative SMT
108981622
AXA005A0X-SRZ
10 – 14Vdc
0.75 – 5.5Vdc
5 A
89.0%
Negative SMT
108995172
-Z refers to RoHS compliant versions
