DEH41054 Installation Instructions
g g
Record Plus™ Record Plus™
Molded Case Circuit Breaker
Accessories
Molded Case Circuit Breaker
Accessories
CAUTION: This product is NOT suitable for use
in equipment not specifically design to accept it.
Contact the equipment manufacturer for possible
equipment modifications.
ATTENTION: Cet appareil nedoit pas etre
employe dans un equipement non specialement
adapte a cet effet. Contactez le constructeur
concernant les possibles modifications
Wire Connector Kits
Congratulations and thank you for choosing the
Record Plus™ family of current-limiting circuit
breakers. This UL-listed lug connector kit is suitable
for use with the FE 250 circuit breaker series.
Record Plus™ circuit breakers are designed with a
full line of integrated accessories. All units use the
latest in integrated modular circuit breaker
technology for flexibility in application and
maximizing the product’s utilization and
capabilities.
Record Plus™ circuit breakers are listed by
Underwriters Laboratories to the UL489 standard.
Record Plus™ circuit breakers and their accessories
are designed and manufactured to exceed our global
customers’ high standards for reliability and quality.
Warning: DANGER of electrical shock or injury.
Ensure ALL electrical power supplies are OFF
before installing or removing any devices. Do not
remove circuit protective devices until the power
is turned OFF. The breaker, trip unit, or
accessories MUST ONLY be installed and
serviced by QUALIFIED personnel. See NEMA
publication AB4.
Avertissement: Danger contre les risques
d'électrocutions. S'assurer avant TOUTES
manipulations du disjoncteur que les différentes
sources d'alimentation sont en position OFF. Les
disjoncteurs, unités de protection, ou accessoires
doivent être installés par des personnes qualifiées
et habilitées. Ne pas retirer l’appariel de
protection avant que l’alimentation soit coupée.
Lira NEMA publication AB4.
[3]
[2]
[1]
Figure 1a. Lug kit components.
[5]
[4]
Available
only in
LV Kit
Figure 1b. Control wire terminal kit components.
