Your AF 600 FP Bypass Panel comes with an AF 600 FP Adjustable Frequency Drive from GE Drives mounted on
or in an enclosure which contains the following equipment to manually or automatically allow motor operation
across-the-line in addition to motor operation from the drive.
ABB
Non-Fused Disconnect w/through-the-door lockable handle (or equivalent)
ABB
Fused Disconnect w/through-the-door lockable handle (optional) (or equivalent)
GE Spectra RMS
TM
Mag-Break Solid State Circuit Breaker w/through-the-door lockable handle
GE C-2000
TM
3-Pole Non-Reversing Contactors
GE C-2000
TM
Class 20/30 Fixed Heater Motor Overload Relays
GE C-2000
TM
Selector Switches and Pilot Lights
GE Type IP Encapsulated or Vacuum Impregnated 115 VAC Control Power Transformer w/fuses
Bussman/ Ferraz Shawmut Amp-trap
Time-Delay Class J Fuses (or equivalent)
GE Line Reactors (optional)
GE Load Reactors (optional)
GE DC Link Reactors (Drive inbuilt)
These instructions are intended as a supplement to the User’s Guide for the AF 600 FP drive. For programming,
operating and troubleshooting instructions for the adjustable frequency drive please refer to this instruction
manual, which is included with your bypass panel documentation package.
DET - 609
AF 600 FP User’s Guide for up to 60HP @ 208V @ & up to 125HP @460/575
DET - 610
AF 600 FP User’s Guide for 150HP and above @ 460/575V
Also included with your bypass panel documentation package are installation instructions, electrical and
mechanical drawings of your bypass panel, and a parts list that includes recommend spares.
DEH40602
– Page 1
AN 11-2021 Rev 05, 12/15/2011
OPERATING AND TROUBLESHOOTING INSTRUCTIONS FOR
AF 600 FP BYPASS PANELS
