56
Table B
6KFP Series Non-Bypass Configuration -Electrical
Channel
HP Ratings
Estimated Watt Loss (Watts) at
208V 460V 575V
2 225 181 187
3 266 192 216
5 373 232 290
7.5 488 366 374
10 540 450 448
15 739 517 499
20 966 642 666
25 1133 764 734
30 1261 821 797
40 1863 1090 987
50 2034 1208 1147
60 2422 1336 1331
75 - 1719 1696
100 - 2101 2074
125 - 2256 2228
150 - 4283 4083
200 - 4977 -
250 - 5902 -
300 - 6770 -
DEH40603
– Page 10 AN 12-1007 Rev 05, 04/04/2012
