52
Table – 3 (575V)
Device AF - 600 HP Rating(s) Minimum Wire Size Maximum Wire Size Required Torque
Load Reactor (6KFP
Series) 1 through 5 # 22 AWG # 10 AWG 4.5 lb. in.
7.5 through 20 # 14 AWG # 6 AWG 16 lb. in.
25 through 40 # 18 AWG # 4 AWG 16 lb. in.
50 through 100 # 6 AWG 1/0
45 (6 - 4AWG), 50
(2-1/0 AWG)
125 # 2 AWG 4/0 150 lb. in.
150 Note 2 Note 2 Note 1
Load Reactor (6KFP*L
Series) - 3% Z
1 through 10 # 22 AWG # 10 AWG 4.5 lb. in.
15 through 20 # 14 AWG # 6 AWG 16 lb. in.
25 # 18 AWG # 4 AWG 16 lb. in.
30 through 75 # 6 AWG # 1/0
45 (6 - 4AWG), 50
(2-1/0 AWG)
100 through 650 Note 2 Note 2 Note 1
Load Reactor (6KFP*L
Series) - 1% Z
1 through 10 # 22 AWG # 10 AWG 4.5 lb. in.
15 through 20 # 14 AWG # 6 AWG 16 lb. in.
25 # 22 AWG # 14 AWG 16 lb. in.
30 # 14 AWG # 6 AWG 16 lb. in.
40 through 75 # 6 AWG # 1/0
45 (6 - 4AWG), 50
(2-1/0 AWG)
100 through 650 Note 2 Note 2 Note 1
Control Terminal Board 2 through 300 # 26 AWG # 10 AWG Note 1
Note (1): For unmentioned torques, Refer UL508A tables in tab "UL508A" in the same excel file
Note (2): The input and output terminals have Busbars provision for motor connections.
DEH40603 – Page 6 AN 12-1007 Rev 05, 04/04/2012
