GE Industrial Solutions Spectra G-Frame MCCB with microEntelliGuard trip unit User Manual
Page 2
SG PC 36 04 L4 R 6
Code
Description
Function
n
o
i
t
a
n
g
i
s
e
D
e
m
a
r
F
0
0
6
G
S
G
S
HC
35kA at 480Vac
LC
65kA at 480Vac
PC
100kA at 480 Vac
HH
35kA at 480Vac
LL
65kA at 480Vac
PP
100kA at 480 Vac
e
g
a
t
l
o
V
L
U
x
a
M
,
s
e
l
o
P
c
a
V
0
0
6
,
s
e
l
o
P
3
6
,
3
01
150 Amps
04
400 Amps
06
600 Amps
L3
LSI
L4
LSIG
L5
LSIA
L7
LSI-CP
X
None
K
Neutral Protection
Z
ZSI (ST/GF)
T
ZSI (ST/GF/INST)
R
RELT
L
ZSI (ST/GF) + RELT
M
ZSI (ST/GF) + Neutral Protection
N
ZSI (ST/GF) + RELT + Neutral Protection
V
RELT + Neutral Protection
P
ZSI (ST/GF/INST) + RELT
S
ZSI (ST/GF/INST) + Neutral Protection
W
ZSI (ST/GF/INST) + RELT + Neutral Protection
X
Metering (Basic)
2
Metering (Basic) + Modbus
6
Metering (Adv) + Modbus + Waveform Capture
8
Metering (Adv) + Modbus + Waveform Capture + Protective Relays
Advanced Protection
Functions
Advanced Features &
Communications
L = Long Time
S = Short Time
I = Instantaneous
G = Ground Fault
A = Ground Fault Alarm
CP = Control Power
Interruption Rating
Max Amps
Standard Protection
Functions
Standard UL Rating
100% Continuous UL Rating
Table 1. Catalog numbering system for Spectra RMS™ SG Frame breakers with microEntelliGuard™ trip units
GEH-700 Installation Instructions
Example – a breaker with catalog number
SGPC3604L4R6 has the following features:
1 SG600 frame (SG)
2 100 kA at 480 Vac Standard UL rating (PC)
3 3 pole, 600 Vac maximum (36)
4 400 A sensors (04)
5 Long-time, Short-time, Instantaneous and Ground
Fault functions (L4)
6 RELT – Reduced Energy Let-Through (R)
7 Advance Metering, Modbus Communications, and
Waveform Capture (6)
2. Following the instructions supplied with the rating
plug, install the plug into the breaker body. Available
rating plugs, with their catalog numbers, are listed in
Table 2.
Table 2. SG Frame Rating Plugs
SG (Max Amps)
Catalog Numbers
Trip Amps
150
400
600
GTP0060U0101
60
x
GTP0080U0101
80
x
GTP0100U0103
100
x
GTP0125U0103
125
x
GTP0150U0104
150
x
x
GTP0200U0204
200
x
GTP0225U0306
225
x
x
GTP0250U0407
250
x
x
GTP0300U0408
300
x
x
GTP0350U0408
350
x
x
GTP0400U0410
400
x
x
GTP0450U0612
450
x
GTP0500U0613
500
x
GTP0600U0616
600
x
