Summary of Supported PMBus Commands
This section outlines the PMBus command support for the EBDW025A0B bus converters. Each supported command is outlined in
order of increasing command codes with a quick reference table of all supported commands included at the end of the section.
Each command will have the following basic information.
Command Name [Code]
Command support
Data format
Factory default
Additional information may be provided in tabular form or other format, if necessary.
OPERATION [0x01]
Command support: On/Off Immediate and Margins (Act on Fault). Soft off with sequencing not supported and Margins (Ignore
Fault) not supported. Therefore bits 6, 3, 2, 1 and 0 set as read only at factory defaults.
Format 8 bit unsigned (bit field)
Bit Position 7 6 5 4 3 2 1 0
Access r/w r r/w r/w r r r r
Function ON/OFF Bits[5:4] Bits[3:2] N/A
Default Value 1 0 0 0 1 0 0 0
ON_OFF_CONFIG [0x02]
Command support: Bit 1 polarity will be set based upon module code [0=Negative on/off logic, 1=positive on/off logic to allow
customer system to know hardware on/off logic
Format 8 bit unsigned (bit field)
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r/w r r
Function (reserved) Bit 4 pu Bit 3 cmd Bit 2 cpr Bit 1 pol Bit 0 cpa
Default Value 0 0 0 1 1 1
module
code
1
CLEAR_FAULTS [0x03]
Command support: All functionality
STORE_DEFAULT_ALL[0x11]
Command support: All functionality – Stores operating parameters to EEprom memory.
RESTORE_DEFAULT_ALL[0x12]
Command support: All functionality – Restores operating parameters from EEprom memory.
VOUT_MODE[0x20]
Command support: Supported. Factory default: 0x14 – indicates linear mode with exp = -12
Format 8 bit unsigned (bit field)
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r r
Function
Mode (linear) 2’s complement exponent
Default Value 0 0 0 1 0 1 0 0
VOUT_COMMAND [0x21]
Data format: 16 bit unsigned mantissa (implied exponent per VOUT_MODE)
Factory default: 12.000V ( 12.00 / 2
-12 → 49,152 = 0xC000 )
Range limits (max/min): 13.200V/5.000V
Units: volt
Command support: Supported, except when Trim function is selected via MFR_C1_C2_ARA_CONFIG [0xE0].
VOUT_CAL_OFFSET [0x23]
Range limits (max/min): +0.25/-0.25
Units: volt
Command support: read/write support, lockout per MFR_DEVICE_TYPE, functionality implemented
