Data Sheet
October 5, 2009
FNW500R Power Modules; DC-DC Converters
36 – 75 Vdc Input; 28Vdc Output; 500W Output
Document No: DS07-013 ver1.21
PDF name: fnw500r.ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Code
Input Voltage
Output
Voltage
Output
Current
Efficiency
Connector
Type
Product codes
Comcodes
48V (36-75Vdc)
28V
18A
91%
Through hole
FNW500R4
CC109141223
48V (36-75Vdc)
28V
18A
91%
Through hole
FNW500R64-18
CC109141388
Table 3. Device Options
Option
Device Code Suffix
Auto restart (hiccup) protection
4
Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
6
Unthreaded heatsink mounting holes
18
