Austin SuperLynx
TM
SIP Non-isolated Power Modules:
3.0 – 5.5Vdc Input; 0.75Vdc to 3.63Vdc Output; 16A output current
LINEAGE
POWER
18
Document No: DS03-085 ver. 1.53
PDF name: austin-superlynx-sip-ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 3. Device Codes
Product codes
Input
Voltage
Output
Voltage
Output
Current
Efficiency
3.3V @ 16A
Connector
Type
Comcodes
AXH016A0X3
3.0 – 5.5Vdc 0.75 – 3.3Vdc
16A
95.0% SIP
108979592
AXH016A0X3Z
3.0 – 5.5Vdc 0.75 – 3.3Vdc
16A
95.0% SIP
CC109104964
AXH016A0X3-12*
3.0 – 5.5Vdc 0.75 – 3.3Vdc
16A
95.0% SIP
108993434
* Special code, consult factory before ordering
The -12 code has a 100Ω resistor between sense and output pins, internal to the module. Standard code, without
the -12 suffix, has a 10Ω resistor between sense and output pins.
-Z refers to RoHS-compliant versions.
Table 4. Device Option
Option**
Suffix***
Long Pins 5.08 mm ± 0.25mm (0.200 in. ± 0.010 in.)
5
** Contact Lineage Power Sales Representative for availability of these options, samples, minimum order quantity and lead times
*** When adding multiple options to the product code, add suffix numbers in the descending order
