ESTW025A0F Series Eighth-Brick Power Modules
36–75Vdc Input; 3.3Vdc Output; 25A Output
Document No: DS09-013 ver.1.01
PDF name: ESTW025A0F.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes Input Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
ESTW025A0F41Z 48V (36-75Vdc) 3.3V 25A Negative Through hole CC109158498
ESTW025A0F41-HZ 48V (36-75Vdc) 3.3V 25A Negative Through hole CC109159505
ESTW025A0F41-SZ 48V (36-75Vdc) 3.3V 25A Negative Surface Mount CC109159496
ESTW025A0F641 48V (36-75Vdc) 3.3V 25A Negative Through hole CC109159125
ESTW025A0F4Z 48V (36-75Vdc) 3.3V 25A Positive Through hole CC109168118
ESTW025A0F641Z 48V (36-75Vdc) 3.3V 25A Negative Through hole CC109169363
ESTW025A0F841Z 48V (36-75Vdc) 3.3V 25A Negative Through hole CC109167367
ESTW025A0F64-18HZ 48V (36-75Vdc) 3.3V 25A Positive Through hole CC109172846
Table 2. Device Options
Characteristic Definition
Form Factor E E = Eighth Brick
Family Designator ST ST = Stingray Series
Input Voltage W W = Wide Range, 36V-75V
Output Current 025A0 025A0 = 0 25.0 Amps Maximum Output Current
Output Voltage F F = 3.3V nominal
Omit = Default Pin Length shown in Mechanical Outline Figures
6 6 = Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
8 8 = Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)
Omit = Latching Mode
4 4 = Auto-restart following shutdown (Overcurrent/Overvoltage)
Omit = Positive Logic
1 1 = Negative Logic
Customer Specific XY XY = Customer Specific Modified Code, Omit for Standard Code
Omit = Standard open Frame Module
H
H = 1/8th Brick size heat plate, for
use with heat sinks (not available with –S option)
18H
18H = 1/4th Brick size heat plate with unthreaded inserts for
use in coldwall applications (not available with –S option)
S = Surface mount connections
Omit = RoHS 5/6, Lead Based Solder Used
Z Z = RoHS 6/6 Compliant, Lead free
Character and Position
R
a
ti
ngs
Pin Length
Action following
Protective
On/Off Logic
RoHS
O
p
ti
ons
Mechanical Features
