Retrofill Doors Assemblies for AKD-5, AKD-6, and AKD-8
DEH-41563 02/12
AKR30S 30” DOOR ASSY
Level
Seq#
Item Number
Rev
Description
Quantity
UM
Item Type
GCAT
10108090G1
1
AKR30S 30" DOOR ASSY
1
EA (each)
_1
0
10108090PV1
1
PCVU
0
EA (each)
Phantom
_1
1
10103266P1
2
Door, AKR30S- 30"
1
EA (each)
Phantom
__2
CDE22557
0
13GA, CR, B8A3A
30.564
LB (pound)
Raw Material
_1
2
10106237P1
2
ESCUTCHEON, AK-25
1
EA (each)
Purchased
_1
3
10106444P1
2
ESCUTCHEON SEAL
1
EA (each)
Purchased
_1
4
10106452P1
2
GASKET SPT, SIDES. AKD8
2
EA (each)
Purchased
_1
5
10106453P1
2
GASKET SPT, TOP & BTM
2
EA (each)
Purchased
_1
6
10100923P2
3
CERRATED BELLEVILLE WASHER M3
12
EA (each)
Purchased
_1
7
10102274P1
2
POZIDRIV CROSS RECESD PAN HEAD
12
EA (each)
Purchased
_1
8
75C149385P014
12
BRACKET
1
PC (piece)
KB Stock Make
__2
R/M
45130172
1
B8A3A .112 X 49 X 120
0.0651
LB (pound)
KB Purchase Stock
_1
9
75V100058P104
7
RIVET POP
2
EA
Purchased
_1
10
75C149310G002
14
HINGE PIN
1
PC (piece)
RO Make
__2
2
75C149310P002
14
2P!BOTTOM HINGE PLT
1
PC (piece)
Manufactured
___3
R/M
52140127
1
B4A2C .187 X .75
0.121
LB (pound)
KB Purchase Stock
__2
3
75A106200P201
10
WP! HINGE PIN "SIENNA"
1
PC (piece)
Purchased
_1
11
N84P16006B6
0
SCREW,STEEL MACH 10-32X3/8
4
EA
Purchased
_1
12
0317A8780P001
5
HANDLE-NONLOCKING
1
PC (piece)
Purchased
_1
13
75C149310G001
14
HINGEPIN
1
PC (piece)
RO Make
__2
1
75C149310P001
14
WP! TOP HINGE PLATE
1
PC (piece)
Manufactured
___3
R/M
52140127
1
B4A2C .187 X .75
0.121
LB (pound)
KB Purchase Stock
__2
3
75A106200P201
10
WP! HINGE PIN "SIENNA"
1
PC (piece)
Purchased
_1
14
10108739P1
2
DOOR LABEL, RETROFILL
1
EA (each)
Purchased
_1
15
10108741P1
2
CAUTION LABEL, RETROFILL
1
EA (each)
Purchased
_1
16
10109191G1
1
PACKAGING FOR BUMPED OUT DOOR
1
EA (each)
Phantom
__2
1
10109187P1
1
PACKING BOX FOR BUMPEDOUT DOOR
1
EA (each)
Purchased
__2
2
10102425P1
1
Small Bag
1
GM (gram)
Purchased
__2
3
10102426P1
1
PET band
0
MT (meter)
Purchased
__2
4
10102427P1
1
Paper Tape
0
MT (meter)
Purchased
