FLTR100V10 Filter Module
Tyco Electronics Power Systems, Inc.
3000 Skyline Drive, Mesquite, TX 75149, USA
+1-800-526-7819 FAX: +1-888-315-5182
(Outside U.S.A.: +1-972-284-2626, FAX: +1-972-284-2900)
http://power.tycoelectronics.com
Tyco Electronics Corporation reserves the right to make changes to the product(s) or information contained herein without notice. No liability is assumed as a result of their use or application.
No rights under any patent accompany the sale of any such product(s) or information.
© 2003 Tyco Electronics Power Systems, Inc. (Mesquite, Texas) All International Rights Reserved.
Printed in U.S.A.
March 2008 (rev e)
FDS01-04 4EPS (Replaces FDS01-043EPS)
Ordering Information
Option Codes
Device Code Comcode Description
FLTR100V10 107742447 Standard Pin Length
FLTR100V610 108799131 0.145 in. Pin Length
FLTR100V810 108799123 0.110 in. Pin Length
FLTR100V10-62 108997607 0.180 in. Pin Length
FLTR100V10-62Z CC109103801 0.180 in. Pin Length
RoHS compliant
FLTR100V10Z 109100154 Standard Pin Length
RoHS compliant
FLTR100V610Z CC109103264 0.145 in. Pin Length
RoHS compliant
FLTR100V810Z CC1091103272 0.110 in. Pin Length
RoHS compliant
Option
Device Code
Suffix
Short pin: 2.8 mm ± 0.25 mm
(0.110 in. ± 0.010 in.)
8
Short pin: 3.7 mm ± 0.25 mm
(0.145 in. ± 0.010 in.)
6
Short pin: 4.6 mm ± 0.25 mm
(0.180 in. ± 0.010 in.)
-62
