GE
Datasheet
EHHD036A0F Series: DC-DC Converter Power Module
18 to 75V
dc
Input; 3.3V
dc
, 36A, 120W Output
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243
, or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.gecriticalpower.com
February 28, 2014
©2014 General Electric Corporation. All rights reserved.
Version 1.2
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes
Input Voltage
Output
Voltage
Output
Current
On/Off Logic
Connector
Type
Comcodes
EHHD036A0F 41Z
24/48V (18-75Vdc)
3.3V
36A
Negative
Through hole
150029666
EHHD036A0F 41-HZ
24/48V (18-75Vdc)
3.3V
36A
Negative
Through hole
150029824
EHHD036A0F 41-18HZ
24/48V (18-75Vdc)
3.3V
36A
Negative
Through hole
150029826
EHHD036A0F 41-SZ
24/48V (18-75Vdc)
3.3V
36A
Negative
Surface mount
150029825
Table 2. Device Coding Scheme and Options
Characteristic
Definition
Form Factor
E
E = 1 /8th Brick
Family Designator
HH
HH = Hammerhead™ Series
Input Voltage
D
D = UltraWide Range, 18V-75V
Output Current
036A0
036A0 = 036.0 Amps Maximum Output Current
Output Voltage
F
F=3.3V Nominal
Omit = Default Pin Length shown in Mechanical Outline Figures
6
6 = Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
8
8 = Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)
Omit = Positive Logic
1
1 = Negative Logic
Customer Specific
XY
XY = Customer Specific Modified Code, Omit for Standard Code
Omit = Standard open Frame Module
H = 1/8th Brick size heat plate, for use with heat sinks (not available
with -S option)
18H = 1/4th Brick size heat plate with unthreaded inserts for use in
coldwall applications (not available with -S option)
S = Surface Mount connections
Omit = RoHS 5/6, Lead Based Solder Used
Z Z = RoHS 6/6 Compliant, Lead free
4 = Auto-restart following shutdown (Overcurrent/Overvoltage)
Must be ordered
On/Off Logic
Mechanical Features
RoHS
Character and Position
H
18H
S
Ra
ti
ng
s
Op
ti
on
s
Pin Length
Action following
Protective Shutdown
4
