Geh-5626p3-p4, Attention – procedure for aluminum terminations – GE Industrial Solutions Spectra Series Power Panelboards AMC2FJ, AMC6FLS, AMC3FLS, AMC2FLS User Manual
Page 3
Filler Plate
Cat. No.
Module Type
AFP3SFD
AMC6FJ
AMC4FJ
AFP3SFS
AMC3FJ
AMC2FJ
AFP4SFD
AMC6FLS
AMC4FLS
AFP4SFS
AMC3FLS
AMC2FLS
Table 1. Filler plate kit for each breaker module type.
Attention – Procedure for Aluminum
Terminations
1.
Strip the insulation, being careful to not nick the wire.
2.
Clean the wire strands with a wire brush.
3.
Thoroughly coat the stripped conductor with a
suitable antioxidant compound, such as ALNOX or
PENETROX A13.
4.
Insert the conductor and tighten the connector screw
to the indicated torque, as indicated on the rating
label.
