EntelliGuard R Circuit Breaker Retrofill AKD-8 Installation Manual DEH-41549 02/12
Falling Object
•
Do not walk or remain under any heavy assembly while
hoisted above head as the chains securing the
assembly may give way
• Ensure lifting equipment has capability for device being lifted.
• Wear hard hat, gloves, and safety shoes.
• Failure to comply with these instructions could result in serious injury.
PRODUCT DAMAGE
• Ensure circuit breaker and its accessories
are always used within their designated
ratings.
• Do not allow the circuit breaker to hit a
hard surface while handling.
•
Do not drag or slide the circuit breaker
across a hard or rough surface
• A factory-installed rejection feature prevents mismatching circuit breakers and cassettes/
substructure, preventing the insertion of a circuit breaker with a lower rating into a higher rated
cassette/substructure, or the insertion of a higher rated circuit breaker into a lower rated
cassette/substructure.
By following the procedures below, you should be able to install the breaker with minimum effort
and time.
Quality Assured
All EntelliGuard R circuit breakers have been designed and manufactured to the highest technical standards.
Strict procedures ensure first class product quality.
Information Check Sheet
On the side wall of each circuit breaker there is a detailed factory-assembled, side label that details all
features included on both the circuit breaker and on the trip unit.
Product and Catalogue Serial Numbers
Product and catalogue serial numbers should be kept handy when communicating about the circuit breaker.
Each circuit breaker has a unique serial number located on the left side (viewed from front) of the front
fascia.
Environmental Conditions
This indicates failure to comply with these instructions may result in product damage.
