Data Sheet
September 4, 2013
EVW010A0B Series Power Modules
36 – 75Vdc Input; 12.0Vdc Output; 10A Output Current
Document No: DS09-006 ver. 1.2
PDF name: evw010_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes
Input Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
EVW010A0B41Z 48V
(36-75Vdc) 12V 10A Negative Through
hole CC109143203
EVW010A0B64Z 48V
(36-75Vdc) 12V 10A Positive Through
hole CC109156015
EVW010A0B641Z 48V
(36-75Vdc) 12V
10A Negative Through
hole CC109158473
EVW010A0B41-HZ 48V
(36-75Vdc) 12V
10A
Negative Through
hole CC109152781
EVW010A0B41-SZ 48V
(36-75Vdc) 12V
10A
Negative Surface
mount CC109153516
Table 2. Device Options and Coding Scheme
Characteristic
Character and Position Definition
Ra
tings
Form Factor
E
E = Eighth Brick
Family Designator
V
Input Voltage
W
W = Wide Input Voltage Range, 36V -75V
Output Current
010A0
010A0 =
0
10.0 Amps Rated Output Current
Output Voltage
B
B = 12.0 Vout Nominal
Options
Pin Length
Omit = No Pin Trim
6
6 = Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
8
8 = Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)
Action following
Omit = Latching Mode
Protective Shutdown
4
4 = Auto-restart following shutdown (Overcurrent/Overvoltage)
On/Off logic
Omit = Positive Logic
1
1 = Negative Logic
-
Customer Specific
XY
XY = Customer Specific Modified Code, Omit for Standard Code
Mechanical Features
Omit = Standard open Frame Module
H
H = Heat plate (not available with –S option)
S
S = Surface mount connections
RoHS
Omit = RoHS 5/6, Lead Based Solder Used
Z Z = RoHS 6/6 Compliant, Lead free
