CAR1248TN series rectifier
Input: 90Vac to 264Vac; Output: -54Vdc @ 1200W
November 20, 2012 ©2012 General Electric Company. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings only, functional
operation of the device is not implied at these or any other conditions in excess of those given in the operations sections of the data sheet.
Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage: Continuous
All
V
IN
0 264 V
ac
Operating Ambient Temperature T
A
-10 70 1 °C
Storage Temperature T
stg
-40 85 °C
I/O Isolation voltage to Frame (100% factory Hi-Pot tested) 1500 V
ac
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, load, and temperature conditions.
INPUT
Parameter Device Symbol Min Typ Max Unit
Operational Range
All
V
IN
90 110/230 264 V
ac
Frequency Range F
IN 47 50/60 63 Hz
Main Output Turn_OFF V
IN 70 80 V
ac
Maximum Input Current V
IN
= 180V
ac
I
IN
7.9
12.75
A
ac
(V
O
= V
O, set
, I
O
=I
O, max
) V
IN
= 100V
ac
Cold Start Inrush Current
I
IN
40 A
peak
(Excluding x-caps, 25C, <10ms, per ETSI 300-132)
Efficiency Vin= 230V
ac

90
85
%
(T
amb
=25C, V
out
= -54Vdc, I
O
=I
O, max
) Vin= 90V
ac
Power Factor
(V
in
=230V
ac
, I
O
=I
O, max
)
PF 0.99
Holdup time V
in
= 230V
ac
(V
out
= -54Vdc, T
amb
25C, I
O
=I
O, max
) V
in
= 90V
ac
T
16.7
20
ms
Early warning prior to loss of DC output below regulation 2 ms
Ride through T 8.3 ms
Leakage Current
(V
in
= 250V
ac
, Fin = 60Hz)
I
IN
3 mA
rms
Isolation Input/Output 3000 V
ac
Input/Frame 1500 V
ac
Output/Frame 500 V
dc
-54V
dc
MAIN OUTPUT
Parameter Device Symbol Min Typ Max Unit
Output Power High Line Operation 180 – 264 V
ac
All
W
0 - 1200 W
Low Line Operation 90 – 132V
ac
0 - 1000 W
Set point
V
out
-53.9 -54.00 -54.1 V
dc
Overall regulation (load, temperature, aging) -3 +3 %
Ripple and noise 2 540 mV
p-p
32 dBrnc
Turn-ON overshoot +3 %
1 Derated above 50C at 2.5%/C
2 Measured across a 10µf electrolytic and a 0.1µf ceramic capacitors in parallel. 20MHz bandwidth
