GE Energy
CAR2024FP series rectifier
Input: 90Vac to 264Vac; Output: 24 Vdc @ 83A; 3.3Vdc or 5 Vdc @ 1A
March 28, 2013 ©2012 General Electric Company. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings only, functional
operation of the device is not implied at these or any other conditions in excess of those given in the operations sections of the data sheet.
Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage: Continuous All VIN 0 264 V
ac
Operating Ambient Temperature All TA -10 70 1 °C
Storage Temperature All Tstg -40 85 °C
I/O Isolation voltage to Frame (100% factory Hi-Pot tested) All 1500 V
ac
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, load, and temperature conditions.
INPUT
Parameter Device Symbol Min Typ Max Unit
Operational Range All V
IN
90 110/230 264 V
ac
Frequency Range (ETSI 300-132-1 recommendation) All F
IN 47 50/60 63 Hz
Main Output Turn_OFF All
V
IN 85 V
ac
Maximum Input Current V
IN
= 100V
ac
All I
IN
14.3
12.6
A
ac
(V
O
= V
O, set
, I
O
=I
O, max
) V
IN
= 180V
ac
Cold Start Inrush Current
All I
IN
40 A
peak
(Excluding x-caps, 25C, <10ms, per ETSI 300-132)
Efficiency 100% load
All 
90
90
84
%
(T
amb
=25C, V
in
= 230V
ac
, V
out
= 24Vdc, I
O
=I
O, max
) 50% load
20% load
Power Factor (Vin=230Vac, I
O
=I
O, max
) All PF 0.99
Holdup time 2 V
in
= 220V
ac
(Vout= 24V
dc
, Tamb 25C, I
O
=I
O, max
) V
in
= 100V
ac
All T 15
15
ms
Early warning prior to loss of DC output below regulation All 3 ms
Ride through All T 10 ms
Leakage Current (Vin= 250Vac, Fin = 60Hz) All I
IN
3 mArms
Isolation Input/Output
All
3000 V
ac
Input/Frame 1500 V
ac
Output/Frame 100 V
dc
24V
dc
MAIN OUTPUT
Parameter Device Symbol Min Typ Max Unit
Output Power HL / LL [180 – 264 / 90-132 Vac] V
dc
≥ 24V
dc
All W
0 - 2000/1200 W
V
dc
= 21V
dc
0 - 1743/1050 W
Set point All
V
out
23.976 24.00 24.024 V
dc
Overall regulation (load, temperature, aging) All -3 +3 %
Ripple and noise 3
All 240 mV
p-p
Turn-ON overshoot All +3 %
Turn-ON delay All T 2 sec
1 Derated above 50C at 2.5%/C
2 24V output can decay down to 20V
3 Measured across a 10µf electrolytic and a 0.1µf ceramic capacitors in parallel. 20MHz bandwidth
