GE Data Sheet
CAR2512FP series rectifier
Input: 90V
AC
to 264V
AC
; Output: 12 V
DC
@ 2500W; 3.3V
DC
or 5 V
DC
@ 1A
April 23, 2013 ©2013 General Electric Company. All rights reserved. Page 3
12V
DC
MAIN OUTPUT (continued)
Parameter Symbol Min Typ Max Unit
Remote ON/OFF delay time 40 ms
Turn-ON rise time (10 – 90% of V
OUT
) 50 ms
Transient response 50% step [10%-60%, 50% - 100%]
(dI/dt – 1A/µs, recovery 300µs)
V
OUT
-5 +5 %V
OUT
Programmable range (hardware & software) 10.8 13.2 V
DC
Overvoltage protection, latched
(recovery by cycling OFF/ON via hardware or software)
13.8 14.8 15.8 V
DC
Output current [V V
IN
= HL
V
IN
= LL
I
OUT
0
208
100
A
DC
Current limit, Hiccup (programmable level) 110 130 % of FL
Active current share -5 +5 % of FL
STANDBY OUTPUT
Parameter Symbol Min Typ Max Unit
Set point V
OUT
3.3 / 5.0 V
DC
Overall regulation (load, temperature, aging) V
OUT
-5 +5 %
Ripple and noise 50 mVp-p
Output current I
OUT
0 1 A
DC
Isolation Output/Frame 100 V
DC
General Specifications
Parameter Min Typ Max Units Notes
Reliability 400,000 Hrs
Full load, 25C ; MTBF per SR232 Reliability
protection for electronic equipment, method I,
case III,
Service Life 10 Yrs Full load, excluding fans
Weight
Kgs
(Lbs)
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions. See
Feature Descriptions for additional information.
Parameter Symbol Min Typ Max Unit
Remote ON/OFF (Needs to be pulled HI via an external resistor)
Logic High (Module ON) I
IH
 20 µA
V
IH
0.7V
DD
 12 V
DC
Logic Low (Module OFF) I
IL
  1 mA
V
IL
0  0.8 V
DC
