GE Data Sheet
CAR2512FP series rectifier
Input: 90V
AC
to 264V
AC
; Output: 12 V
DC
@ 2500W; 3.3V
DC
or 5 V
DC
@ 1A
April 23, 2013 ©2013 General Electric Company. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings only, functional
operation of the device is not implied at these or any other conditions in excess of those given in the operations sections of the data sheet. Exposure
to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Symbol Min Max Unit
Input Voltage: Continuous V
IN
0 264 V
AC
Operating Ambient Temperature T
A
-10 70 1 °C
Storage Temperature T
STG
-40 85 °C
I/O Isolation voltage to Frame (100% factory Hi-Pot tested) 1500 V
AC
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, load, and temperature conditions.
INPUT
Parameter Symbol Min Typ Max Unit
Operational Range V
IN
90 110/230 264 V
AC
Frequency Range (ETSI 300-132-1 recommendation) F
IN 47 50/60 63 Hz
Main Output Turn_OFF V
IN 80 V
AC
Maximum Input Current (V
OUT
= V
O, set
, I
OUT
=I
O, max
) V
IN
= 100V
AC
I
IN
14.3
16
A
AC
V
IN
= 180V
AC
Cold Start Inrush Current
I
IN
40 A
PEAK
(Excluding x-caps, 25C, <10ms, per ETSI 300-132)
Efficiency (T
AMB
=25C, V
IN
= 230V, V
OUT
= 12V, I
O, max
), 100% load

91.6
92.5
90.0 % 50% load
20% load
Power Factor (V
IN
=230V
AC
, I
OUT
=I
O, max
) PF 0.99
Holdup time 2 (V
OUT
≥ 10.8V
DC
, Tamb 25C, I
OUT
=I
O, max
) V
IN
= 230V
AC
V
IN
= 100V
AC
T
12
15
ms
Early warning prior to output falling below regulation 2 ms
Ride through, high line T 10 ms
Leakage Current (V
IN
= 250V
AC
, Fin = 60Hz) I
IN
3 mArms
Isolation Input/Output 3000 V
AC
Input/Frame 1500 V
AC
Output/Frame 100 V
DC
12V
DC
MAIN OUTPUT
Parameter Symbol Min Typ Max Unit
Output Power HL / LL [180 – 264 / 90-132 V
AC
] V
DC
≥ 12V
DC
W
0 - 2500/1200 W
V
DC
≤ 12V
DC
0 - 2246/1078 W
Set point
V
OUT
11.9 12.00 12.1 V
DC
Overall regulation (load, temperature) -2 +2 %
Ripple and noise 3 -120 +120 mV
p-p
Turn-ON overshoot +3 %
Turn-ON delay T 2 sec
1 Derated above 50C at 2.5%/C
2 12V output can decay down to 10.8V
3 Measured across a 10µf electrolytic and a 0.1µf ceramic capacitors in parallel. 20MHz bandwidth
