Universal Audio Realtime Rack - Manual (Page 98)

Realtime Rack Manual Chapter 4: Realtime Rack Application 98
Reassign Insert
1. Single-click any populated insert button in any View screen to switch into Channel
view and select the insert. The PLUG-IN tab is selected and the plug-in interface
is displayed.
2. Single-click the ASSIGN tab. The CATEGORY button of the current plug-in is se-
lected, along with the PRESET column (and SUB-FOLDER column, if any).
3. Single-click any CATEGORY button to select it. The plug-ins within the category
are displayed in the PLUG-IN column. Use the vertical scroll bar to view all the
plug-ins if necessary.
4. Single-click any plug-in the PLUG-IN column to assign it to the insert. The old
plug-in is replaced by the new plug-in with its default preset, and the PRESETS
column (and SUB-FOLDER column, if any) are displayed.
5. If desired, single-click any preset in the PRESETS column (or SUB-FOLDER col-
umn, if any) to load the preset. Use the vertical scroll bar to view all the presets
and/or sub-folders if necessary.
Done. Exit assign mode by pressing enter or clicking a different element. Click the
PLUG-IN tab to view the plug-in’s interface and edit parameters.
De-assign Insert
Tip: Plug-in de-assignment in Inserts View via the Remove function can be much
quicker, especially when removing numerous plug-ins.
1. Single-click any populated insert button in any View screen to switch into Channel
view and select the insert. The PLUG-IN tab is selected and the plug-in interface
is displayed.
2. Single-click the ASSIGN tab. The CATEGORY button of the current plug-in is se-
lected, along with the PRESET column (and SUB-FOLDER column, if any).
3. Single-click the NONE category button. The plug-in is removed from the insert
and UAD resources used by the plug-in are released.
Done. Exit assign mode by pressing enter or clicking a different element.
Tip: Plug-ins can also be de-assigned using the shortcut on the
insert buttons (shown at right). For details, see
page 87 .
