Apollo Software Manual Chapter 9: Device Drivers 124
Apollo I/O, Single Unit, PT Mode On, 4x Sample Rates
Apollo Driver I/O
Single Unit – PT Mode On
176.4 kHz & 192 kHz Sample Rates
INPUTS OUTPUTS
1 NULL 1 1 MON L
2 NULL 2 2 MON R
3 MIC/LINE/Hi-Z 1 3 LINE 1
4 MIC/LINE/Hi-Z 2 4 LINE 2
5 MIC/LINE 3 5 LINE 3
6 MIC/LINE 4 6 LINE 4
7 LINE 5 7 LINE 5
8 LINE 6 8 LINE 6
9 LINE 7 9 LINE 7
10 LINE 8 10 LINE 8
11 ADAT 1 11 ADAT 1
12 ADAT 2 12 ADAT 2
13 ADAT 3 13 ADAT 3
14 ADAT 4 14 ADAT 4
15 S/PDIF L 15 S/PDIF L
16 S/PDIF R 16 S/PDIF R
17 MON L* 17 HP1 L
18 MON R* 18 HP1 R
19 AUX1 L*
20 AUX1 R*
21 HP1 L*
22 HP1 R*
*Software Outputs
(for DAW inputs)
