Mustang Motorcycle Seats Wide Touring Studded Recessed Rear Seat Yamaha Roadliner - Manual (Page 2)

7KHVHVWHSVDUHJXLGHOLQHVWRKHOS\RXLQVWDOO\RXUQHZ0XVWDQJSURGXFW,I\RXQHHGIXUWKHU
DVVLVWDQFHSOHDVHFDOOXVDW0RQGD\WKURXJK)ULGD\(DVWHUQRUVHQG
DQHPDLOWRTXHVWLRQV#PXVWDQJVHDWVFRPRUYLVLWRXUZHEVLWHDWZZZPXVWDQJVHDWVFRP
)RUFDUHDQGPDLQWHQDQFHRIRXUVHDWVSOHDVHJRWRRXUZHEVLWHXQGHU6XSSRUW
5HISDUW¶V
Enjoy the comfort of
your new Mustang Seat!
Mounting of Mustang Seat
Our seat is installed just like the stock seat. The passenger seat
must be installed first.
Passenger Seat
1. Slide the tongue on the rear seat bracket into the U-
bracket on the fender.
2. Push the seat back until the seat bracket aligns with the
front fender bracket holes.
3. Install the stock 8 mm bolts through bracket and tighten
with a 10 mm wrench.
Solo Seat
4. Slide the solo seat rear bracket into the fender mounted
receiver. Note: Make sure that the tool bag is not
overstuffed and be sure it sits into the frame as low as
possible.
5. Push the solo seat back until it stops.
6. Align the nose bracket with the frame receiver and push
down until a click is heard. The solo is now locked. To
remove solo, insert ignition key into the left side cover
and turn counterclockwise. The nose is now unlocked.
Step 1
Step 3
Step 4
