Mustang Motorcycle Seats Two-Piece Vintage Seat with Driver Backrest - Harley-Davidson VRSCA & VRSCB, No Studs - Manual (Page 2)

Mounting of Mustang Seat
Note: When installing the Mustang two-piece seat, the passenger seat must be installed before the solo seat. When mounting
Mustang's seat with the stock sissy bar in place, you must push down on the passenger seat very hard and compress the foam
to engage the bracket.
Mustang Passenger Seat
1. Align the rear seat receiver bracket with the motorcycle’s fender tongue.
2. Slide the Mustang seat back engaging the seat rear bracket under the fender tongue bracket.
3. Install the stock seat 8 mm bolt to the front bracket of Mustang rear seat with a 13 mm wrench.
Removal of Stock Seat continued
Stock Passenger Seat
5. Remove the one mounting bolt from frame with a 13 mm wrench.
6. Slide seat forward and off of fender tongue.
7. Remove hand strap and bolts from fender. You are now ready to install your new Mustang
Two-Piece Seat.
Step 5 Step 6 Step 7
Step 1 Step 2
Step 3
Mounting Suggestions: Harley-Davidson® V-Rod: VRSCA & VRSCB Two-Piece Seat
continued from page 1)
page 2
Updated 10/14/10 AA
