B: User Interface
166-00000-000-02-0110 49
Icon Description
Displays the integration time (in Spectrometer Mode).
Displays the averages of the specified number of scans (all modes).
Displays the number of shots to take and the average (Single and Continuous Shot
Modes).
Allows you to manually take a scan (Single Shot Mode).
Resets the spectrometer (in the event that a trigger is missed).
Not used.
Takes the specified number of cleaning shots. This option is configured in the Setup
Options window.
Turns the alignment light on or off.
Status Bar
The OOILIBSplus Status Bar, located at the bottom of the screen, features the following options:
Option Description
Displays the wavelength, counts
and pixel number of the current
cursor location.
Displays the current Q Switch
delay.
Displays the current Continuous
Save File name (when in use).
