3: Operation
166-00000-000-02-0110 29
Option Description
Intg Mean Integrated mean/average of all count scans taken.
Intg Std Dev Integrated standard deviation of all count scans taken.
Intg RSD Integrated residual standard deviation of all count scans taken.
Count Number of scans taken for each line. This value is used in the calculations
described above.
Lines Information
Option Description
Wavelength Wavelength assigned to the currently selected line. You can change this value, and
set the custom value for a custom line.
Place the graph cursor at the desired position and click the cursor button to set this
value.
Left Left wavelength, or L Wave.
Place the graph cursor at the desired position and click the cursor button to set this
value.
Right Right wavelength, or R Wave.
Place the graph cursor at the desired position and click the cursor button to set this
value.
Update Save the information to the currently selected line. No changes will be made until
you click the update button.
Peak Analysis Procedure
► Procedure
Follow the instruction below to use the Peak Analysis Mode:
1. Select Mode | Peak Analysis from the menu. The Peak Analysis screen appears.
