166-00000-000-02-0110 39
Appendix A
Specifications
Specification Value
Dimensions for 7-channel
version (LxWxH):
33.4 cm x 15 cm x 14 cm (13.2 x 5.9 x 5.5 in.)
Weight for 7-channel
version:
6.36 kg (14.1 lbs.)
Spectrometer range: 200-980 nm
Resolution: 0.1 nm (FWHM)
Detection: CCDs with a combined 14,336 pixels
Frame rate: 10 Hz capability, computer-controlled
Integration time: 2.1 ms; variable in the free-run mode
Trigger delay: -121 s to +135 s in 500 ns steps, computer-controlled
Trigger jitter: +/-250 ns
Trigger level: TTL not to exceed 5.5 V
Computer connection: USB 1.1 (in all computers)
Software: OOILIBSplus
Power requirement: 5 volts at <1 amp, power supply included
Input optical fiber:
2-meter, multimode sampling probe with SMA connector and
collimating lens
Size for 7 Channels:
84HP x 3U Rack Housing with handles (130 mm x 483 mm x 350
mm)
Certification: CE
