H Series IP Camera User Manual – with Pan/Tilt of CMOS
18
There are two frequencies on the world, one is 50HZ, and the other is 60HZ. In China,
adopt 50HZ.
7） Audio input mode: If user use microphone , please select “MIC”; if use line-in audio
signal (like sound pick-up), please select “Line in”.
8） OSD Setting: User can add the equipment’s name and the time on the video page
thorough this setting.
7.2 Network Setting Page
7.2.1 Basic Network Setting
Figure 18
1） LAN Setting: The default setting of this equipment is showed as above Figure 18, user
can change it according to your network environment.
2） HTTP Port: The IP address Identity one IP camera in the network, you can run several
programs on this equipment, and every program will transfer the data through some port,
in fact data is transferred from one port to another. The port setting of this page is asking
user choose which port to transfer the data for the web server.
3） WIFI Setting: The wireless setting page is showed as below Figure 19, user can click the
“Search” button, and it will show you the page telling you the WIFI network it has
detected. Please choose one of it, and the network data will filled in the blanks
automatically. (For example, SSID, encryption algorithm etc). User only needs to fill in
the password and retype the password . After you configured it, you can click the
“Check” button to check if there is any mistake. Check is success, please click “Apply”
button to set it.
Make sure the IP camera you are using is /W model before configuring the WIFI
setting.
