Plug Top Power Adaptors
PPT10 Series
10 Watt Switch Mode
Universal AC Input
Features
•
Universal Input: 90 - 264Vac
•
Continuous Short Circuit Protection
•
Conductive EMI Meets CISPR/FCC Class B
•
High Efficiency, 75% Typical
•
Interchangeable AC plug
•
Optional output connector
INPUT
Voltage
90-264 VAC
Frequency
47-63 Hz
Input current
0.4A max
Inrush current
30A max. @ 264VAC
Isolation
Input to output = 4,242VDC
Leakage Current
0.25mA max
OUTPUT
Holdup Time
10mS typ. @ 115VAC
Short Circuit Protection
Continuous (Auto Recovery)
Overcurrent protection
Constant Current type
ENVIRONMENTAL
Operating temperature
0°C to 40°C
Storage temperature
-20°C to +85°C
GENERAL
Dimensions
72x46x35 mm
Weight
132 grams approx
Typical at 25°C, nominal line and 75% load, unless otherwise specified
Specifications
The PPT10 Series of AC-DC Power Adaptors offer user
interchangeable AC input plugs to enable operation in many different
countries simply by changing the clip on plug.
Adaptors can be ordered with up to 4 different interchangeable plugs
to meet the power socket requirements of most countries.
