AC-DC Converter
CFM05 Series
5 Watt Open Frame
Single Output
Features
• Universal input range 85-264Vac
• Efficiency to 80%
• Meets EN55022 Class B
• Continuous short circuit protection
• Low leakage current 0.25mA max.
• PCB mountable
Input Voltage Range 85 - 264Vac
Frequency 47 - 63Hz
Inrush Current 40A max. @ 240Vac
Conducted EMI CISPR/FCC Class B
Isolation - Input/Output 4242VDC
Leakage Current 0.25mA max.
Hold-up Time 8mS typ. @ 115Vac
Short Circuit Protection Continuous
Temperature Coefficient ±0.05% / °C
Operating Temperature Range 0°C to +70°C at full load (above +70°C derate linearly to 0% load at +85°C)
Storage Temperature Range -20°C to +85°C
Safety Approvals cUL/UL 60950, TUV EN60950
Cooling Natural convection
Dimensions 55.0 x 35.0 x 21.0 mm (2.165 x 1.378 x 0.827 inches)
Weight 35g
Electrical Specification
Typical at 25°C, nominal line and 75% load unless otherwise stated.
www.powersolve.co.uk
Output Voltage and Current Ratings
MODEL OUTPUT OUTPUT CURRENT RIPPLE VOLTAGE LINE LOAD % EFF.
VOLTAGE Min. Max. (mV pk-pk) ACCURACY REG. REG.
CFM05S033 3.3V 0A 1.25A 50mV ±1% ±0.5% ±1% 70%
CFM05S050 5.0V 0A 1.0A 50mV ±1% ±0.5% ±1% 73%
CFM05S120 12.0V 0A 0.42A 120mV ±1% ±0.5% ±1% 79%
CFM05S150 15.0V 0A 0.33A 150mV ±1% ±0.5% ±1% 79%
CFM05S240 24.0V 0A 0.23A 240mV ±1% ±0.5% ±1% 80%
CFM05S090 9.0V 0A 0.55A 90mV ±1% ±0.5% ±1% 78%
CFM05S180 18.0V 0A 0.28A 180mV ±1% ±0.5% ±1% 79%
NOTE:
1. Output noise and ripple measured with 10µF tantalum & 0.1µF ceramic capacitors across output.
2. Line regulation is measured from 100Vac to 240Vac at full load.
3. Load regulation is measured from 10% to 100% of full load.
Derating Curve
