SPECIFICATIONS Preliminary version Power Sink SM3300
Page 1 - 2 February 2013, Preliminary version
Power Sink Spec i fi ca tions
SM18-220
Option P306
SM66-AR-110
Option P308
SM100-AR-75
Option P309 SM330-AR-22
Option P310 SM660-AR-11
Option P311
Sink Power Rat ing
max. peak power (elec tron i cally lim ited)
max. continuous power (T
amb
. = 25 °C)
max. continuous power (T
amb
. = 50 °C)
300W
300W
t.b.d
Max. du ra tion Sink Peak Power
P
sink
=P
max
, T
amb
. = 25 °C
Duty Cy cle for use at Peak Power
P
sink
=P
max
, T
amb
. = 25 °C
con tin u ous @ P
sink
= 300 W
100% @ P
sink
= 300 W
Max. Sink Cur rent
(V
o
>= 2 V and P <= P
max
)
Lim ited at
75 A
Lim ited at
75 A
Lim ited at
75 A
Lim ited at
10 A
Lim ited at
10 A
Pro tec tion Elec tronic Power Limit lim its the cur rent.
The tem per a ture of the power sink is fan con trolled and
the cir cuit shuts down in case of ther mal over load.
Re cov ery time / De vi a tion
Vo = 6 V, I
o
: +100 A → –30 A
re cov ery within 100 mV / de vi a tion:
Vo = 15 V, I
o
: +100 A → –10 A
re cov ery within 100 mV / de vi a tion:
Vo = 24 V, I
o
: +70 A → –7.5 A
re cov ery within 100 mV / de vi a tion:
Vo = 60 V, I
o
: +35 A → –3 A
re cov ery within 100 mV / de vi a tion:
Vo = 300 V, I
o
: +8 A → –0.5 A
re cov ery within 1 V / de vi a tion:
Vo = 600 V, I
o
: +4 A → –0.25 A
re cov ery within 1 V / de vi a tion:
(load cur rent switches from pos i tive
to neg a tive)
di/dt = – 2.5A/µs
400 µs / 0.30 V
di/dt = – 2.5A/µs
450 µs / 0.30 V
-
-
-
-
note: val ues
are typ i cal
di/dt = – 2.5A/µs
750 µs / 1.20 V
di/dt = – 2.5A/µs
600 µs / 0.85 V
di/dt = – 1.5A/µs
1.1 ms/ 0.90 V
di/dt = – 1.0A/µs
2.0 ms/ 0.90 V
-
-
note: val ues
are typ i cal
-
-
di/dt = –1.8A/µs
600 µs / 0.65 V
di/dt = – 0.8A/µs
2.2 ms/ 0.60 V
-
-
note: val ues
are typ i cal
-
-
-
-
di/dt = – 0.3A/µs
1.0 ms/ 1.9 V
-
note: val ues
are typ i cal
-
-
-
-
di/dt = – 0.15A/µs
0.5 ms/3.0 V
di/dt = – 0.07A/µs
1.5 ms/ 3.0 V
note: val ues
are typ i cal
Pro gram ming Down Speed
Fall time at no load (90 - 10%)
Fall time at no load with out Power Sink
Fall time at no load (90 - 10%)
Fall time at no load with out Power Sink
Unit with Fast Pro gram ming Op tion
Fall time at no load (90 - 10%)
Fall time at no load with out Power Sink
Fall time at no load (90 - 10%)
Fall time at no load with out Power Sink
(6 → 0 V)
2.3 ms
1.2 s
(18 → 0 V)
14.8ms
4.2 s
P306+P300
(6 → 0 V)
0.09ms
23ms
(18 → 0 V)
0.3ms
34ms
(33 → 0 V)
5.6ms
3.5 s
(66 → 0 V)
23ms
5.0 s
P308+P302
(33 → 0 V)
0.55 ms
150ms
(66 → 0 V)
1.5ms
600ms
(50 → 0 V)
11 .5ms
2 .3 s
(100 → 0 V)
45.0ms
9.4 s
P309+P303
(50 → 0 V)
0.48ms
60.6ms
(100 → 0 V)
1.4ms
425ms
(165 → 0 V)
14 ms
3.5 s
(330 → 0 V)
50 ms
12 s
P310+P304
(165 → 0 V)
1.5 ms
600 m s
(330 → 0 V)
4.8 ms
2 s
(330 → 0 V)
12 ms
3.5 s
(660 → 0 V)
45 ms
11 s
P311+P305
(330 → 0 V)
2.2 ms
720 ms
(660 → 0 V)
8 ms
3.8 s
Par al lel and Se ries op er a tion
Re fer to power sink man ual for
de tails and re stric tions. Us ing mul ti ple units in par al lel op er a tion, only one unit can have a power sink .
Us ing mul ti ple units in se ries op er a tion, all units must have a power sink .
SM66-AR-110 with Power Sink Op tion
fast dis charge of out put ca pac i tors
by Power Sink circuit
Trace: out put volt age
Volt age Pro gram ming Speed at NO LOAD
SM66-AR-110 with out Power Sink Op tion
slow re sponse time dur ing volt age step down,
time needed to dis charge the out put ca pac i tors
Trace: out put volt age
Volt age Pro gram ming Speed at NO LOAD
• The maximum sink current at higher voltages will not be the maximum specified current due to the power limit.
For example for an SM66-AR-110 at 30V, the max sink current will be 10 A (30 V x 10 A = 300 W = max power).
• A higher sink current than the maximum current will cause the output voltage to rise.
Notes:
