High Density DC-DC Modules
AS75 Series
30 - 84 Watt
DC-DC Converters
Single Output
Features
•
2:1 Input Voltage Range
•
Eighth brick package
•
Regulated outputs
•
Efficiency to 92%
•
1500VDC isolation
•
Input under voltage protection
•
Over current protection
•
Over temperature protection
INPUT
Input Voltage Range
36 ~ 75V
Undervoltage Lockout
35V (Vin power up)
33V (Vin power down)
Positive Logic Remote ON/OFF
Open Collector ref. to -Input, Module ON: Open Circuit, Module OFF: <1.2VDC
Add suffix N to Model No. for Negative Logic Remote ON/OFF
Input Filter
PI Type (12V version: LC type)
OUTPUT
Voltage Accuracy
±1.0% max.
Transient Response: 25% Step Load Change
<400µsec
External Trim Adj. Range
±10%
Ripple & Noise, 20MHz BW
100mV pk-pk max. measured with 10µF tantalum & 1.0µF ceramic capacitors
across output
ENVIRONMENTAL
Temperature coefficient
±0.03%/°C max.
Short Circuit Protection
Continuous / Hiccup
Line Regulation
±0.2% max over input voltage range
Load Regulation
±0.5% max from 0-100% load
Over Voltage Protection trip range, % Vo nom.
115 ~ 140%
Current Limit
110% ~ 160% Nominal Output
GENERAL
Efficiency
See table
Isolation Voltage
1500VDC min
Isolation Resistance
10
7
ohms min.
Switching Frequency
250-350KHz depending on output voltage
Over temperature protection
120°C typ.
Operating ambient temperature range
-40°C to +85°C
Storage temperature range
-40°C to +125°C
Dimensions
2.30 x 0.90 x 0.39 inches
58.4 x 22.9 x 10.0 mm
Weight
26g
Electrical Specification
