Powersolve Electronics Ltd. 8A Arnhem Road, Newbury, RG14 5RU. England

Tel: 01635 521858 Fax: 01635 523771 Email: [email protected]

www.powersolve.co.uk

Desk Top Power Supplies

PSG40-60 ES Series
40-60 Watts
Single DC Output

Features

• Meets CEC Requirements
• Universal AC Input
• Conforms to RoHS
• IEC320 C14 3 pin AC input connector
• EMC to EN55022’B’, CISPR22 ‘B’ & FCC ‘B’
• Desk Top Plastic Enclosure
• Optional DC Output Connectors

Electrical Specification

INPUT

Input Voltage

90-264VAC

Input Frequency

47-63Hz

Safety Ground Leakage Current

<1mA max

No Load Input Power

0.5W max

OUTPUT

Output Voltage & Current

See table

Output Power

40-60 Watts see table for models

Output Ripple & Noise

200mV pk-pk max (depending on output voltage)

Transient Response Time

4mS max full load to half load 100VAC input

Line Regulation

1% max

Load Regulation

±5% max

Output Protection

Overcurrent & Overvoltage

ENVIRONMENTAL

Operating Temperature

0 to 40ºC, ambient

Storage Temperature

-40ºC to +85ºC

Relative Humidity

5-95% max

GENERAL

Efficiency

>85% average

MTBF

>100,000 hours @ 25ºC calculated to MIL-HDBK-217F

Power On Indicator

LED

SAFETY

Withstand Voltage

Primary to Secondary 4242V DC, Primary to Ground 2121V DC

Isolation Resistance

500Mohm Min

Safety Approvals

UL/cUL60950, TUV/GS(EN60950), CB

EMI/EMC

CISPR22 ’B’, FCC Part 15 ’B’, EN55022 ‘B’

MECHANICAL

UL94V-1 plastic enclosure, dimensions 117.5 x 53 x 31mm, output cable 1.2 metre
